Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Current Rating | 25A A |
| Current, Leakage | 7 mA (Max.) |
| Current, Surge | 250 Apk (Max.) |
| Dielectric Strength | 4000 V (RMS) |
| Height | 2.3" (58.4mm) |
| Input Type | Voltage |
| Length | 1.8" (45.72mm) |
| Power Rating | 0.5 (Min.) |
| Resistance, Thermal, Junction to Case | 1.02 °C⁄W |
| Series | |
| Special Features | Microprocessor Based Phase Angle Controller/SSR |
| Supply Voltage | 180 to 280 VAC |
| Temperature, Ambient | -20 to 80 °C |
| Termination | Screw |
| Thickness | 0.78 in. |
| Type | Control Relay |
| Voltage Rating | 180 to 280 VAC |
Overview
MCPC Series:
